Hey all, I have a 86 dual cab lux, Im trying to figure out what kind of recovery points will work on the back. I did a search on this topic, I looked at over 60pages but got no answers.
At the moment I have hooks on the front.
I was thinking some big ass eyebolts bolted to the rear chassis rail would do the trick, and I was talking to some1 the other day, and he mentioned that the chassis rails at the rear(being a C shape), would most likely bend, so thats out.
So now Im thinking maybe get some more hooks and just bolt them on, maybe with some steel plate top and bottom of chassis as well, to help spread loading. But again, the chassis rail will most likely bend.
Im not running a towbar and have no plans on running one, I have an alloy tray and Im not going to be changing trays anytime soon.
Does anyone have any ideas/pics of what I could do??
Id appreciate it a heap.
Thanks guys and girls.
[/i]
Notice: We request that you don't just set up a new account at this time if you are a previous user.
If you used to be one of our moderators, please feel free to reach out to Chris via the facebook Outerlimits4x4 group and he will get you set back up with access should he need you.
If you used to be one of our moderators, please feel free to reach out to Chris via the facebook Outerlimits4x4 group and he will get you set back up with access should he need you.
Recovery:If you cannot access your old email address and don't remember your password, please click here to log a change of email address so you can do a password reset.
Need ideas for recovery points
Moderators: toaddog, TWISTY, V8Patrol, Moderators
Need ideas for recovery points
MrsForby wrote: Oh I desperately truly love the taco.
the C channel at the back could have a crush tube and extra plating welded on, then the C channel boxed in to create a solid mounting point.
Otherwise, use the chassis rail that runs front to back rather than a crossmember - put crush tube in and run the hook or hoop sideways through the chassis rail - thats pretty much how mines done on the rear of my sierra, with plating either side of the chassis as well.
Otherwise, use the chassis rail that runs front to back rather than a crossmember - put crush tube in and run the hook or hoop sideways through the chassis rail - thats pretty much how mines done on the rear of my sierra, with plating either side of the chassis as well.
The worst thing about censorship is ███████.
Simple is best.
Hayman Reece square coupling towbar, use the pin for you strap, or chain around the bar either side of the tow aperture. (stopping chain sliding to either end of the bar)
Hayman Reece square coupling towbar, use the pin for you strap, or chain around the bar either side of the tow aperture. (stopping chain sliding to either end of the bar)
George Carlin, an American Comedian said; "Think of how stupid the average person is, and realise that half of them are stupider than that".
a comp truck i pulled down just had 2 hooks one bolted to the chassis rail on each side at the rear. seemed fine and wasnt bent.
still have the hooks and plates if you want them cheap.
but yeah the hayman reese set up which is a dime a dozen works well.
still have the hooks and plates if you want them cheap.
but yeah the hayman reese set up which is a dime a dozen works well.
*there's a rock, drive over it :) there's a bigger rock, drive over it :twisted: there's an even bigger rock, oops broke it :oops: Upgrade broken bit :bad-words:
Goto *
Goto *
hey mate.
when i made my tray i got my boilermaker at work to weld a bit of rhs in between chasis rails 75x50x5-6mm i think, fits good. then weld in eyebolts im yet to brace it up but i pull my brothers patrol out with them all the time
if i done it again id make plates up and bolt it to chassis
when i made my tray i got my boilermaker at work to weld a bit of rhs in between chasis rails 75x50x5-6mm i think, fits good. then weld in eyebolts im yet to brace it up but i pull my brothers patrol out with them all the time
if i done it again id make plates up and bolt it to chassis88 hilux - 3rz+ locked
04 prado - that has a second home called toyota service dept
94 comp truck hilux - in the making....
04 prado - that has a second home called toyota service dept
94 comp truck hilux - in the making....
Thanks guys, and you too ajsr but I dont think I will try that.
Preferably, Id have a custom tray and build points into the back of that, but Im not up to there yet.
And Im not towing anything, so a towbar is not needed.
What about this then - hooks on outside of Csection, with steel plate on inside of Csection all bolted together. Ill use plate that is longer than needed and bolt it through chassis as well.
Would that work ok??
Preferably, Id have a custom tray and build points into the back of that, but Im not up to there yet.
And Im not towing anything, so a towbar is not needed.
What about this then - hooks on outside of Csection, with steel plate on inside of Csection all bolted together. Ill use plate that is longer than needed and bolt it through chassis as well.
Would that work ok??
